  CHENGDU DOMA CARBIDE TOOLS CO.,LTD.

  Standard or Customized

  Tungsten Carbide By Sinter-HIP

  40Cr Steel

  Silver-alloy Brazing

  M1020, M1225, SM-3, SM-5

  Available

  Available

Drawing

Diagram of Application

Metric Standard

Shank Dia. (mm)

Cutter Dia. (mm)

Lgth. of Cut (mm)

Overall Lgth. (mm)

Included Angle

Tool No.

The Combination of Head and Shank

d₂

d₁

l₂

l₁

3

3

11

38

14°

M0311

Solid

5

13

51

14°

M0513

Brazed

6

13

51

14°

M0613

Brazed

6

6

18

53

14°

M0618

Brazed

6

25

50

14°

M0625

Solid

8

20

65

25°

M0820

Brazed

10

20

65

25°

M1020

Brazed

12

25

70

25°

M1225

Brazed

16

25

70

31°

M1625

Brazed

8

12

25

70

25°

M1225

Brazed

16

25

70

31°

M1625

Brazed

Inch Standard

Shank Dia. (inch)

Cutter Dia. (inch)

Lgth. of Cut (inch)

Overall Lgth. (inch)

Included Angle

Tool No.

The Combination of Head and Shank

d₂

d₁

l₂

l₁

3/32

3/32

1/4

1-1/4

10°

SM-61

Solid

1/8

1/8

11/32

1-1/2

12°

SM-41

Solid

1/8

7/16

1-1/2

14°

SM-42

Solid

1/8

7/16

2

14°

SM-42L2

Solid

1/8

7/16

3

14°

SM-42L3

Solid

1/8

5/8

1-1/2

7°

SM-43

Solid

3/16

1/2

1-1/2

16°

SM-53

Brazed

1/4

1/2

2-1/9

22°

SM-51

Brazed

1/4

1/4

1/2

2

22°

SM-1

Solid

1/4

3/4

2

14°

SM-2

Solid

1/4

1

2

10°

SM-3

Solid

3/8

5/8

2-1/2

28°

SM-4

Brazed

1/2

7/8

2-3/4

28°

SM-5

Brazed

5/8

1

2-8/9

31°

*SM-6

Brazed
